ANNOVI

제품소개 > 고압 펌프 > ANNOVI REVERBERI

pump type type de pompe Pumptyp tipo de bomba tipo pompa	code code kodex codigo codice	output debit leistung caudal portata		pressure druck pression prestion pressione		power puissance leistung potencia potenza		RPM tours/1 U.P.M Rev/1 N° giri/1	weight poids gewicht peso peso
pump type type de pompe Pumptyp tipo de bomba tipo pompa	code code kodex codigo codice	l/min	gpm	bar	p.s.i.	hp	kw	RPM tours/1 U.P.M Rev/1 N° giri/1	kg
RKA 3.5 G22 N	20658	13.2	3.5	150	2200	5	3.6	1750	9
RKA 3.5 G25 N	20659	13.2	3.5	170	2500	5	3.6	1750	9
RKA 3.5 G30 HN	20660	13.2	3.5	205	3000	7.5	5.5	1750	9.5
RKA 3.5 G40 HN	20661	13.2	3.5	275	4000	10	7.5	1750	9.5
RKA 4 G20 N	20662	15.1	4	140	2000	5	3.6	1750	9
RKA 4 G30 AN	20663	15.1	4	205	3000	7.5	5.5	1750	9
RKA 4 G30 N	20664	15.1	4	205	3000	7.5	5.5	1750	9.5
RKA 4 G30 HN	20665	15.1	4	205	3000	7.5	5.5	1750	9.5
RKA 4 G36 HN	20666	15.1	4	250	3600	10	7.5	1750	9.5
RKA 4 G40 HN	20667	15.1	4	275	4000	11	8.2	1750	9.5
RKA 4.5 G17 N	20668	17	4.5	115	1700	5	3.6	1750	9
RKA 4.5 G25 HN	20669	17	4.5	170	2500	7.5	5.5	1750	9
RKA 4.5 G30 HN	20670	17	4.5	205	3000	10	7.5	1750	9.5
RKA 4.5 G40 HN	21130	17	4.5	275	4000	12.5	9..2	1750	9.5

pump type type de pompe Pumptyp tipo de bomba tipo pompa	code code kodex codigo codice	output debit leistung caudal portata		pressure druck pression prestion pressione		power puissance leistung potencia potenza		RPM tours/1 U.P.M Rev/1 N° giri/1	weight poids gewicht peso peso
pump type type de pompe Pumptyp tipo de bomba tipo pompa	code code kodex codigo codice	l/min	gpm	bar	p.s.i.	hp	kw	RPM tours/1 U.P.M Rev/1 N° giri/1	kg
XWA 7 G35	21139	25.5	7	240	3500	15	11	1750	16
XWA 7 G40	21140	25.5	7	275	4000	17	12.5	1750	16
XWA 8 G19	20182	30.2	7	130	1900	10	7.5	1750	16
XWA 8 G29	20063	30.2	7	200	2900	15	11	1750	16
XWA 8 G35	21141	30.2	8	240	3500	18	13.4	1750	16
XWA 9 G16	20183	34	8	110	1600	10	7.5	1750	16
XWA 9 G24	20064	34	8	170	2400	15	11	1750	16

SXWA 4 G50	21024	15.1	4	345	5000	13	9.5	1750	16
SXWA 5.5 G50	21006	20.8	5.5	345	5000	18	13.4	1750	16
SXWA 7 G50	21211	25.5	7	345	5000	22	16.2	1750	16
